210
Combination Meter Display ( Color LCD )
! ECO gauge s03bn1201
The ECO gauge shows the difference between the average rate of fuel consumption since the trip meter was last reset and the current rate of fuel consumption .
The ECO gauge indicates the current fuel |
efficiency as shown in the following chart . |
Displayed unit |
Needle position
“+” side
“ − ” side
|
MPG |
Better |
Poorer |
l / 100km |
Poorer |
Better |
NOTE
. The ECO gauge shows only an approximate indication .
. After resetting the trip meter , the average rate of fuel consumption is not shown until driving 0.6 miles ( 1 km ). Until that time , the ECO gauge does not operate .
! Clock and outside temperature s03bn1202
This screen displays the clock and outside temperature .
NOTE
. The clock can be displayed in either 12-hour display or 24-hour display . For details , refer to “ General settings ” FP227 ( 11.6- inch display models ) or “ General settings ”
FP245 ( dual 7.0-inch display models ).
. The outside temperature indicator shows the temperature in the area around the sensor . However , the temperature may not be indicated correctly or the update may be delayed in the following conditions . – While parking or driving at low speeds
– When the outside temperature changes suddenly ( example : when going in and out of an underground parking area or when passing through a tunnel )
– When starting the engine after being parked for a certain period of time
. You can set the temperature units to be displayed in Celsius ( 8C ) or Fahrenheit ( 8F ). For details , refer to “ Car settings ” FP232 ( 11.6-inch display models ) or “ Car Settings icon ” FP251 ( dual 7.0-inch display models ).
