Warning and Indicator Lights 183 |
|||||||||||||||||||
3-6. Warning and Indicator Lights |
s03ae
Several of the warning and indicator lights illuminate momentarily and then go out when the ignition switch is initially turned to the“ ON” position. This permits checking the operation of the bulbs.
Apply the parking brake and turn the ignition switch to the“ ON” position. For the system check, the following lights illuminate and turn off after several seconds or after the engine has started:
|
: Seatbelt warning light( The seatbelt warning light turns off only when the driver fastens the seatbelt.)/ Front passenger’ s seatbelt warning light( The seatbelt warning light turns off only when the front seat passenger fastens the seatbelt.)
: Rear seatbelt warning light
: SRS airbag system warning light
: Front passenger’ s frontal airbag ON indicator light
: Front passenger’ s frontal airbag OFF indicator light
/: CHECK ENGINE warning light / Malfunction indicator light
|
: Charge warning light
: Oil pressure warning light
/: ABS warning light
: Vehicle Dynamics Control warning light / Vehicle Dynamics Control operation indicator light
: Vehicle Dynamics Control OFF indicator light
|
/: Brake system warning light
: Electronic parking brake indicator light
: Power steering warning light
: Low tire pressure warning light( U. S.- spec. models)
|
: Low fuel warning light
: Automatic headlight beam leveler warning light
: Auto Start Stop warning light( yellow)
If any lights fail to illuminate, it indicates a burned-out bulb or a malfunction of the corresponding system.
Consult your authorized SUBARU dealer for repair.
|
& Seatbelt Warning Light and Chime s03ae01
Your vehicle is equipped with a seatbelt warning device at the driver’ s and passenger’ s seats, as required by current safety standards.
! Driver’ s and front passenger’ s seats s03ae0114
With the ignition switch turned to the“ ON” position, this device reminds the driver and front passenger to fasten their seatbelts by illuminating the warning lights in the locations indicated in the following illustration and sounding a chime.
Driver’ s seat
|
3
Instruments and Controls
|
||||||||||||
– CONTINUED – |
