152
Windows
Without one-touch auto up and down feature
1 Close 2 Open
NOTE
Avoid the following .
. Continuously operating a switch in the same direction after the window is fully closed or fully opened .
. Continuously operating three or more switches all at once in the same direction after the windows are fully closed or fully opened .
Either of the operations described above may cause the power window breaker to operate making it impossible to open or close the window . Be sure to initialize the power windows . Refer to
“ Initialization of Power Window ( Windows with One-Touch Auto Up and Down Function )” FP153 .
! Anti-entrapment function ( windows with one-touch auto up and down function ) s02ah0703
While closing the window automatically , if the window senses a substantial enough object trapped between the window and the window frame , it automatically moves down slightly and stops .
If a foreign object is caught while window is opening automatically , the window will stop .
CAUTION
. Never attempt to test the power window operation using body parts .
. If an object is caught just before the window fully closes , the system may not operate properly .
NOTE
. If a window detects an impact similar to that caused by trapping an object ( for example , when the vehicle encounters a deep pothole ), the antientrapment function may operate . . You cannot close the window for a
few seconds after the anti-entrapment function operates .
! Off delay function ( windows with one-touch auto up and down function ) s02ah0705
The windows can be operated for approximately 40 seconds even after the ignition switch is turned to the “ ACC ” or “ OFF ” position . If a front door is opened within 40 seconds , the off delay function is canceled .
! Locking the passengers ’ windows s02ah0704
1 Lock 2 Unlock
When the lock switch is in the lock position , the rear passenger ’ s window switches on the driver side door and the passengers ’ window switches cannot be operated .
