holders by pulling up the covers . |
& Roof Rails with Ladder Type ( Subaru Outback Wilderness )
s08aj15
|
|||||||
1 . Check that the rear crossbar is stowed in the front side holder . If the rear crossbar is stowed in the rear side holder , move it back to the front side holder ( original position ). |
3 . Slide the bars in the direction shown in the illustration . |
1 Roof rails
Cargo can be carried on the roof after securing the roof crossbars to the roof rails and installing the appropriate carrying attachments . When installing the roof crossbars and the carrying attachments , follow the manufacturer ’ s instructions . The roof rail system is designed to carry loads ( cargo , roof crossbars and carrying attachments ) of no more than 220 lbs ( 100 kg ). Be sure not to exceed your vehicle ’ s GVWR and GAWR .
|
8
Driving Tips
|
|||||
2 . Pull out the crossbars from the roof rail |
4 . Install the bars into the holders .
5 . Make sure that the latches are fitted securely .
|
CAUTION
. When using the carrying attachments , make sure that the total
– CONTINUED –
|
