BSD / RCTA 419 |
|||||
! System temporary stops due to reduced radar sensitivity s07bm0802 |
& BSD / RCTA Warning Indicator s07bm04
! System malfunction s07bm0403
|
& To Turn On / Off the BSD / RCTA s07bm09 |
|||
|
BSD / RCTA OFF indicator
To turn the BSD / RCTA system on and off , operate the center information display . Refer to “ Car settings ” FP230 ( 11.6-inch display models ).
When the BSD / RCTA system is turned OFF , the BSD / RCTA OFF indicator on the combination meter display ( color LCD ) will illuminate .
NOTE
. In the following cases , turn off the BSD / RCTA system . The system may not operate properly due to blocked radar waves . – When towing ( Outback / Subaru
Outback Wilderness ) – When a bicycle carrier or other
– CONTINUED –
|
|||||
|
1 BSD / RCTA temporary stop message due to reduced radar sensitivity
2 BSD / RCTA OFF indicator
This display appears when the detectability of the rear corner radars is reduced . Once the condition is corrected , the system will recover from the temporary stop condition and the indicator will disappear .
If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer .
|
1 BSD / RCTA malfunction message 2 At first , this message will appear 3 Then this message will appear 4 BSD / RCTA warning indicator
This display appears when a malfunction occurs in the system . Contact a SUBARU dealer and have the system inspected .
|
7
Starting and Operating
|
