418
BSD / RCTA
– Immediately after the BSD / RCTA is activated by touching “ Rear Vehicle Detection ( BSD / RCTA )”
– Immediately after the select lever is shifted to the “ R ” position
– When extremely heavy cargo is loaded in the trunk or cargo area
. During reversing , operation of the BSD / RCTA approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings under the following conditions . – When backing out of an angled parking space – When a large-sized vehicle is parked next to your vehicle ( That vehicle prevents the propagation of radar waves .) – When reversing on sloped roads – When reversing at a high speed
. The BSD / RCTA approach indicator light may illuminate when driving close to solid objects on the road or road side ( such as guardrails , tunnels and sidewalls ).
. When turning at an intersection in urban areas , or a multilane intersection , the BSD / RCTA approach indicator light may flash .
. If a building or a wall exists in the reversing direction , the BSD / RCTA approach indicator light may flash and the warning buzzer may sound .
. In the following cases , the system may detect a vehicle driving two lanes away from your vehicle . – When your vehicle drives on the near side of its lane from the corresponding vehicle
– When the vehicle driving two lanes away drives on the near side of its lane from your vehicle
& BSD / RCTA OFF Indicator s07bm08
! System temporary stops s07bm0801
1 BSD / RCTA temporary stop message 2 BSD / RCTA OFF indicator
This display appears when the system is used at extremely high or low temperatures or when abnormal voltage exists . Once these conditions are corrected , the system will recover from the temporary stop condition and the indicator will disappear .
If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer .
