BSD / RCTA 415 |
||||||
range is limited by the parked vehicle ( B ). Always be sure to check the surroundings with your eyes when reversing the vehicle . |
Example 2
1 The detection range of the rear corner radars
C Vehicle that may be detected
NOTE
The system may detect that a vehicle ( C ) is passing in front of your vehicle . Always be sure to check the surroundings with your eyes when reversing the vehicle .
|
& System Operation
s07bm02
! Operating conditions s07bm0201
The BSD / RCTA will operate when all of the following conditions are met .
. The ignition switch is in the “ ON ” position .
. The BSD / RCTA warning indicator and BSD / RCTA OFF indicator are turned off .
. The vehicle is driven at speeds above 7 mph ( 12 km / h ) ( except when reversing ).
. The select lever is in the “ R ” position ( RCTA only ).
The BSD / RCTA will not operate in the following situations .
. The BSD / RCTA OFF indicator appears .
. The vehicle speed is below 6 mph ( 10 km / h ) even when the BSD / RCTA OFF indicator does not appear ( except when reversing ).
NOTE
. In the following cases , the BSD / RCTA will stop operating and the BSD / RCTA warning indicator will appear . – When a malfunction occurs in the system , including the BSD / RCTA approach indicator light
|
. If the BSD / RCTA warning indicator appears , exercise proper caution . For details , refer to “ BSD / RCTA Warning Indicator ” FP419 .
. In the following cases , the BSD / RCTA will temporarily stop operating ( or may stop operating ) and the BSD / RCTA OFF indicator will appear . – When the rear corner radars become significantly misaligned ( If the orientation of the rear corner radars is shifted for any reason , readjustment is required . Have the sensor adjusted at a SUBARU dealer .)
– When a large amount of snow or ice sticks to the rear bumper surface around the rear corner radars
– When the vehicle is driven on a snow-covered road or in an environment in which there are no objects around ( such as in a desert ) for a prolonged period of time
– When the temperature around the rear corner radars increases excessively due to long driving on uphill grades in the summer , etc .
– When the temperature around the rear corner radars becomes ex-
|
7
Starting and Operating
|
||
– CONTINUED – |
