414
BSD / RCTA
RCTA approach indicator light is illuminating , the system warns the driver of dangers by flashing the BSD / RCTA approach indicator light .
! Lane Change Assist ( LCA ) s07bm010101
The system notifies the driver of vehicles approaching at a high speed in the neighboring lanes .
. If the system detects a vehicle approaching at a high speed in the neighboring lanes , it warns the driver of dangers by illuminating the BSD / RCTA approach indicator light ( s ) on the outside mirror ( s ).
. If the driver operates the turn signal lever in the direction where the BSD / RCTA approach indicator light is illuminating , the system warns the driver of dangers by flashing the BSD / RCTA approach indicator light .
! Rear Cross Traffic Alert ( RCTA ) s07bm0103
. An icon appears on the center information display .
! Limitations of the detectability of RCTA s07bm010301
Since the detectability of RCTA is limited , the RCTA may not operate properly in angled parking .
1 Operating range
1 Operating range
The system notifies the driver of another vehicle approaching from either side when driving in reverse . This feature helps the driver check the rear and side areas of the vehicle when moving backward .
If the system detects a vehicle approaching from either side while moving backward , it warns the driver of dangers in the following way .
. The BSD / RCTA approach indicator light ( s ) on the outside mirror ( s ) flashes .
. A warning buzzer sounds .
Example 1
1 The detection range of the rear corner radars
2 Area out of detection range of the rear corner radars
A Vehicle that may not be detected B Parked vehicle
WARNING
An approaching vehicle ( A ) may not be detected because the detection
