3 |
||||||||
|
1 HomeLink buttons 2 Left button 3 Center button 4 Right button
Press any of the left , center or right buttons to display the main menu . Select HomeLink menu using the left button or press any of the HomeLink buttons .
NOTE
The main menu cannot be displayed on the display while the select lever is in a position other than the “ P ” position .
|
1 . Select “ SET UP ” using the right button .
2 . Select “ Continue ” using the HomeLink left button .
3 . Press any of the HomeLink buttons .
4 . Be sure to read the displayed instructions . Select “ Continue ” using the HomeLink left button .
5 . Position the hand-held remote ( garage door opener remote ) 2 in ( 5 cm ) away from the mirror .
|
1 Garage door opener remote
6 . While the HomeLink programming instructions are displayed , press and hold the hand-held remote button .
NOTE
Some hand-held remotes ( garage door opener remotes ) may actually train better at a distance of 6 to 12 in ( 15 to 30 cm ). Keep this in mind if you have difficulty with the programming process .
7 . Be sure your garage door is not moving , then press OK .
8 . Firmly press the HomeLink left button 3 times . At this point , your device should operate when the HomeLink button is
|
Instruments and Controls |
|||||
– CONTINUED – |
