212
Combination Meter Display ( Color LCD )
Mark Name Page
BSD / RCTA warning indicator ( if equipped )
BSD / RCTA OFF indicator ( if equipped )
Auto Start Stop warning light ( yellow )
Auto Start Stop OFF indicator light
Auto Start Stop indicator light ( green )
Auto Start Stop No Activity Detected indicator light
Automatic headlight beam leveler warning light
Windshield washer fluid warning light
Hill descent control indicator light ( Outback / Subaru Outback Wilderness )
206
206
204
204
205
205
204
195
205
Mark |
Name |
Page |
|
Driver Monitoring System operation indicator light ( green ) ( if equipped ) |
206 |
|
Driver Monitoring System warning light ( yellow |
207 |
|
) ( if equipped ) |
|
|
Driver Monitoring System OFF indicator light
( if equipped )
|
207 |
|
Driver Monitoring System temporary stop indicator light ( if equipped ) |
207 |
Icy road surface warning light
206
& Basic Screens s03bn06
By operating the or switch on the steering wheel , you can change the screen that is always displayed .
Average fuel consumption screen :
AVG : Average fuel consumption : Driving range on remaining fuel
This screen displays the average rate of fuel consumption since the trip meter was last reset .
NOTE
The driving range on the remaining fuel is only a guide . The indicated value may differ from the actual driving range on the remaining fuel , so you must immediately fill the tank when the low fuel warning light illuminates .
