SRS Airbag (Supplemental Restraint System Airbag) 75
anchorage.
5. Tighten the top tether securely. Contact
your SUBARU dealer if you have any
questions regarding the installation of a
child restraint system.
! Outback
s01ag090202
1) When installing on the window-side
seating position
2) When installing on the rear center seating
position
1. Raise the head restraint at the seating
position where the child restraint system is
to be installed with the seatbelt or lower
anchorages.
2. Adjust the seatback to the upright
position.
3. Pass the top tether between the head
restraint and seatback.
4. Attach the top tether hook to the
appropriate upper anchorage.
5. Tighten the top tether securely. Contact
your SUBARU dealer if you have any
questions regarding the installation of a
child restraint system.
1-8. *SRS Airbag (Supplemental
Restraint System Airbag)
s01ah
*SRS: This stands for Supplemental Restraint
System. This name is used because
the airbag system supplements the
vehicle’s seatbelts.
Your vehicle is equipped with a supplemental
restraint system in addition to a lap/
shoulder belt at each front seating position
and each rear window-side seating position.
The supplemental restraint system
(SRS) consists of the following airbags.
. Driver’s and front passenger’s frontal
airbags
. Driver’s and front passenger’s side
airbags
. Front passenger’s seat cushion airbags
. Curtain airbags (for driver, front passenger,
and window-side rear passengers)
. Knee airbag for driver
These SRS airbags are designed only
to be a supplement to the primary
protection provided by the seatbelt.
The system also controls front seatbelt
pretensioners. For operation instructions
– CONTINUED –
1
Seat, Seatbelt and SRS Airbags
