Child Restraint Systems 71
Each lower anchorage is located behind
the cover of seatback bottom.
CAUTION
When you install a child restraint
system, follow the manufacturer’s
instructions supplied with it. After
installing the child restraint system,
check to ensure that it is held
securely in position. If it is not held
tight and secure, the danger of your
child suffering personal injury in the
event of an accident may be increased.
system.
If it is hard to install the child restraint
system because the anchorage cover
returns to the original position, press the
anchorage cover to the seat cushion until it
is flat.
3. If the child restraint system makes
contact with the head restraint of the rear
seating position where the child restraint
system is to be installed, raise the head
restraint to the extended position. If the
child restraint system still makes contact,
remove the head restraint. For details,
refer to “Head Restraint Adjustment”
☞P44.
CAUTION
Store the head restraint that has
been removed in the trunk (Legacy)
or the cargo area (Outback). Do not
place the head restraint in the passenger
compartment to prevent it
from being thrown around in the
passenger compartment in a sudden
stop or a sharp turn.
4. For Outback models, adjust the seatback
to the upright position.
5. While following the instructions supplied
by the child restraint system manufacturer,
connect the lower hooks onto the
lower anchorages located at “ ” marks on
the bottom of the rear seatback. When the
hooks are connected, make sure the
adjacent seatbelts are not caught.
1
Seat, Seatbelt and SRS Airbags
Peel off the anchorage cover completely
from the selected side of the rear seatback
to expose the anchorages (bars) to be
used for installation of the child restraint
– CONTINUED –
