70
Child Restraint Systems
refer to “Top Tether Anchorages” ☞P72.
! To install a child restraint system
using lower and tether anchorages
s01ag070103
WARNING
Before installing a child restraint
system, be sure to confirm that the
seatback is securely locked into
place. Otherwise, in an accident,
serious injury or death could result.
1. Move the seatback back and forth to
confirm that it is securely locked into place.
– Check that the red colored unlocking
marker on the lock release button is
not visible. For details, refer to “Folding
Down the Rear Seatback” ☞P41.
For U.S. spec. models
Outback
1) For left seat
2) For center seat
3) For right seat
The tether anchorages (upper anchorages)
are provided at the locations
shown in the above illustration. For details,
Other models
2. You will find “ ” marks at the bottoms
of the rear seatback. These marks indicate
the positions of the lower anchorages
(bars).
