Front Seats 37
head restraints are designed to
be installed into the rear seats
only. Do not attempt to install the
front seat head restraints into the
rear seats, or the rear seat head
restraints into the front seats.
Both the driver’s seat and front passenger’s
seat are equipped with head restraints.
Both head restraints are adjustable
in the following ways.
! Head restraint height adjustment
s01aa0401
1) Head restraint
2) Release button
To raise:
Pull the head restraint up.
To lower:
Push the head restraint down while pressing
the release button on the top of the
seatback.
To remove:
While pressing the release button, pull out
the head restraint.
To install:
Install the head restraint into the holes that
are located on the top of the seatback until
the head restraint locks. Press and hold
the release button to lower the head
restraint.
Each head restraint should be adjusted so
that the center of the head restraint is
closest to the top of the occupant’s ears.
NOTE
It is not possible to remove or install the
head restraint without reclining the
front seatback. Reclining the front seatback
and then remove or install the
head restraint.
! Head restraint angle adjustment
s01aa0402
The angle of the head restraint can be
adjusted in several steps. While maintaining
a suitable driving posture, adjust the
head restraint to a position where the back
of your head is as close to the head
restraint as possible.
To tilt:
Tilt the head restraint by hand to the
preferred position. A click will be audible
when the head restraint is locked.
To return:
Tilt the head restraint once as far forward
as it can go. The head restraint will
automatically return to the fully upright
– CONTINUED –
1
Seat, Seatbelt and SRS Airbags
