198
Combination Meter Display (Color LCD)
Speed Screen” ☞P204.)
5) Telltale screen (Refer to “Telltale Screen”
☞P200.)
6) Select lever/gear position indicator (Refer
to “Select Lever/Gear Position Indicator”
☞P193.)
7) X-MODE indicator (Outback) (Refer to
“X-MODE Indicator (Outback)” ☞P195.)
SI-DRIVE indicator (if equipped) (Refer
to “SI-DRIVE Indicator Light” ☞P193.)
8) Odometer (Refer to “Odometer”
☞P171.)/Double trip meter (Refer to
“Double Trip Meter” ☞P172.)
*: For details, refer to the separate EyeSight
Owner’s Manual.
& Basic Operation
Control switches
1)
2)
3)
s03bn01
By operating or of the control
switches, the screens can be changed.
If there are some useful messages, such
as vehicle information, warning information,
etc., they will interrupt the current
screen, and appear on the display accompanied
by a beep. If such a screen is
displayed, take proper action according to
the message shown on the screen.
The warning screen will return to the
original screen after a few seconds. While
the information reminder is shown on
the display, it may be possible to display
the warning screen again. To recall the
message marked with on the display,
pull the switch on the steering wheel
toward you.
& Welcome Screen (Opening
Animation) and Good-Bye
(Ending Animation) Screen
s03bn08
When the driver’s door is opened and
closed after unlocking the door, the welcome
screen (opening animation) will
appear on the combination meter display
(color LCD) for approximately 20 seconds.
When the ignition switch is turned to the
“LOCK”/“OFF” position, the combination
meter display (color LCD) gradually turns
off by showing good-bye screen (ending
animation).
NOTE
. The welcome screen and the goodbye
screen may differ in the actual
words and appearance.
. The basic screen will be shown
when the ignition switch is turned to
the “ON” position while the welcome
screen is displayed.
. Once the welcome screen appears, it
takes a certain period of time to display
it again.
. If the ignition switch is operated
after unlocking the driver’s door, the
