172
Meters and Gauges
& Double Trip Meter
s03ad05
trip or B trip meter, then press and hold the
TRIP RESET switch.
& Fuel Gauge
s03ad07
CAUTION
To ensure safety, do not attempt to
change the function of the indicator
during driving, as an accident could
result.
1) TRIP RESET switch
2) Trip meter
This meter displays the two trip meters
when the ignition switch is in the “ON”
position.
The trip meter shows the distance that the
vehicle has been driven since you last set
it to zero.
The display can be switched as shown in
the following sequence by pressing the
TRIP RESET switch.
To reset the trip meter, select either the A
NOTE
. If the connection between the combination
meter and battery is broken for
any reason such as vehicle maintenance
or fuse replacement, the data
recorded on the trip meter will be lost.
. If you press the TRIP RESET switch
when the ignition switch is in the
“LOCK”/“OFF” or “ACC” position, the
odometer/trip meter will light up. It is
possible to switch between the A trip
meter and B trip meter indications while
the odometer/trip meter is lit up.
In addition, it is possible to reset the trip
meter by pressing and holding the TRIP
RESET switch.
The indicators will turn off when the
TRIP RESET switch is not operated for
approximately 10 seconds.
The fuel gauge shows the approximate
amount of fuel remaining in the tank.
When the ignition switch is in the “LOCK”/
“OFF” or “ACC” position, the fuel gauge
shows “E” even if the fuel tank contains
fuel.
The gauge may move slightly due to fuel
level movement in the tank (e.g., during
braking, turning or acceleration).
NOTE
. You will see the “ ” sign in the fuel
gauge. This indicates that the fuel filler
lid is located on the right side of the
vehicle.
. If you press the TRIP RESET switch
while the ignition switch is in the
