Meters and Gauges 171
3-4. Meters and Gauges
s03ad
NOTE
Liquid crystal displays are used in
some of the meters and gauges in the
combination meter. You will find their
indications hard to see if you wear
polarized glasses.
& Speedometer
s03ad03
The speedometer shows the vehicle
speed.
NOTE
The initial movement of the meter
needles and gauge needles that occurs
when the ignition switch is turned to the
“ON” position can be activated or
deactivated.
For details, refer to “General settings”
☞P211 (11.6-inch display models) or
“General settings” ☞P229 (dual 7.0-
inch display models).
& Tachometer
s03ad06
The tachometer shows the engine speed
in thousands of revolutions per minute.
CAUTION
Do not operate the engine with the
pointer of the tachometer in the red
zone. In this range, fuel injection will
be cut by the engine control module
to protect the engine from overrevving.
The engine will resume running
normally after the engine speed
is reduced below the red zone.
NOTE
The initial movement of the meter
needles and gauge needles that occurs
when the ignition switch is turned to the
“ON” position can be activated or
deactivated.
For details, refer to “General settings”
☞P211 (11.6-inch display models) or
“General settings” ☞P229 (dual 7.0-
inch display models).
& Odometer
1) TRIP RESET switch
2) Odometer
s03ad04
This meter displays the odometer when
the ignition switch is in the “ON” position.
The odometer shows the total distance
that the vehicle has been driven.
NOTE
If you press the TRIP RESET switch
when the ignition switch is in the
“LOCK”/“OFF” or “ACC” position, the
odometer/trip meter will light up. The
indicators will turn off when the TRIP
RESET switch is not operated for
approximately 10 seconds.
– CONTINUED –
