Windows 145
! Operating the window
s02ah0702
“Initialization of Power Window (Windows
with One-Touch Auto up and
down Function)” ☞P146.
With one-touch auto up and down feature
1) Automatically close*
2) Close
3) Open
4) Automatically open*
*: To stop the window halfway, operate the
switch to the opposite side.
Without one-touch auto up and down
feature
1) Close
2) Open
NOTE
Avoid the following.
. Continuously operating a switch in
the same direction after the window is
fully closed or fully opened.
. Continuously operating three or
more switches all at once in the same
direction after the windows are fully
closed or fully opened.
Either of the operations described
above may cause the power window
breaker to operate making it impossible
to open or close the window. Be sure to
initialize the power windows. Refer to
! Anti-entrapment function (windows
with one-touch auto up and down
function)
s02ah0703
While closing the window automatically, if
the window senses a substantial enough
object trapped between the window and
the window frame, it automatically moves
down slightly and stops.
If a foreign object is caught while window is
opening automatically, the window will
stop.
CAUTION
. Never attempt to test the power
window operation using body
parts fingers, hands or other
parts of your body.
. If an object is caught just before
the window fully closes, the system
may not operate properly.
NOTE
. If a window detects an impact similar
to that caused by trapping an object (for
example, when the vehicle encounters
a deep pothole), the anti-entrapment
function may operate.
– CONTINUED –
