Starting and operating/Reverse Automatic Braking System
When the OFF setting is shown, the
corresponding setting is OFF.
Touch and hold the OFF setting key to turn
the setting ON.
When the Reverse Automatic Braking
system and/or the object detection warn-
ing beeping sounds are turned OFF, the
following indicator(s) will illuminate.
1)
2)
RAB OFF indicator: illuminates when the
Reverse Automatic Braking system is
turned OFF.
Sonar audible alarm OFF indicator: illu-
minates when the object detection warn-
ing beeping sound is turned OFF.
Each indicator will turn off when the
corresponding function is turned ON.
7-67
NOTE For details, refer to “RAB” F3-47.
. When the settings cannot be chan-
ged, the ON/OFF setting key will be
grayed out.
. The settings cannot be changed for
approximately 14 seconds after turning
the ignition switch to the “ON” position.
. The ON/OFF setting key may be
greyed out if the Reverse Automatic
Braking system malfunctions, etc. In
this case, turn the ignition switch to the
“LOCK”/“OFF” position and then turn it
to the “ON” position again. If the setting
cannot be changed even after turning
the ignition switch to the “ON” position
again, consult your SUBARU dealer.
. The settings will be restored as
follows when the select lever is shifted
to the “R” position next time.
– Reverse Automatic Braking sys-
tem settings: default (ON setting)
– Object detection warning beep-
ing sound: the setting selected by
operating the audio/navigation
monitor
Also, the following settings can be chan-
ged by operating the multi information
display.
. Warning volume
. Sonar audible alarm & Handling of the sonar sen-
sors
S07BN06
The 4 sonar sensors are located in the rear
bumper. To ensure the proper operation of
the Reverse Automatic Braking system,
observe the following precautions.
. Do not affix any stickers or other items
on the bumper surface near the sonar
sensors.
. Always keep the rear bumper surface
near the sonar sensors clean.
. Do not modify the rear bumper.
. Do not paint the bumper near the sonar
sensors.
. Do not apply strong impacts to the rear
bumper near the sonar sensors. If a sensor
– CONTINUED –
