Instruments and controls/Mirrors
the device during the “cycling” process
to prevent possible overheating.
Proceed with “Programming a New
HomeLink ® button” step 4 to complete.
! Using HomeLink ®
S03AP100303
To operate, simply press and release the
programmed HomeLink ® button. Activa-
tion will now occur for the trained device
(i.e. garage door opener, gate operator,
security system, entry door lock, home/
office lighting, etc.). For convenience, the
hand-held remote of the device may also
be used at any time.
! Erasing HomeLink ® buttons
S03AP100304
To erase programming from the three
buttons (individual buttons cannot be
erased but can be “reprogrammed” as
outlined below), follow the step noted:
Press and hold the two outer HomeLink ®
buttons for at least 10 seconds. The LED
indicator will change from continuously lit
to rapidly flashing. Release both buttons.
Do not hold for longer than 20 seconds.
HomeLink ® is now ready to be pro-
grammed at any time beginning with
“Programming a New HomeLink ® button”
- step 1.
! Reprogramming a Single
HomeLink ® button
S03AP100305
To program a previously trained button,
follow these steps:
1. Press and hold the desired HomeLink ®
button. DO NOT release the button.
2. The indicator light will begin to slowly
flash orange after 20 seconds. The
HomeLink ® button can be released at this
point. Proceed with “Programming a New
HomeLink ® button” - step 3.
3. If you do not complete the program-
ming of a new device to the button, it will
revert to the previously stored program-
ming.
3-83
Range may be reduced by obstacles such
as houses or trees. You may have to slow
your vehicle speed to successfully receive
the garage door opener communication.
! Programming Two-Way Commu-
nication
S03AP100307
! Garage Door Two-Way Commu-
nication
S03AP100306
HomeLink ® has the capability of commu-
nicating with your garage door opener.
HomeLink ® can receive and display “clos-
ing” or “opening” status messages from
compatible garage door opener systems.
At any time, HomeLink ® can also recall and
display the last recorded status commu-
nicated by the garage door opener to
indicate your garage door being “closed”
or “opened”. Within 5 seconds after programming a new
HomeLink ® button, both of HomeLink’s
garage door status indicators will flash
rapidly green indicating that the garage
door two-way communication has been
enabled. If your garage door status in-
dicators flashed, two-way communication
programming is complete.
HomeLink ® has the capability of receiving
this communication from the garage door
opener at a range up to 820 feet (250 m). If the garage door status indicators do not
flash, additional HomeLink ® information
and programming videos can be found
1)
Status Indicators
– CONTINUED –
