3-82
Instruments and controls/Mirrors
7. Return to the vehicle and firmly press,
hold for 2 seconds and release the
HomeLink ® button up to three times. At
this point programming is complete and
your device should operate when the
HomeLink ® button is pressed and re-
leased.
1)
Status Indicators
8. If status indicator arrows appear next
to the indicator light, please refer to
“Garage Door Two-Way Communication”
F3-83.
In the event that there are still program-
ming difficulties or questions, additional
HomeLink ® information and programming
videos can be found at
www.HomeLink.com and
www.youtube.com/HomeLinkGentex. For
Genie and Sommer garage door openers
please go directly to the HomeLink ®
website.
! Gate Operator / Canadian Pro-
gramming
S03AP100302
Canadian radio-frequency laws require
transmitter remote signals to “time-out”
(or quit) after several seconds of transmis-
sion, which may not be long enough for
HomeLink ® to pick up the signal during
programming. Similar to this Canadian
law, some U.S. gate operators are de-
signed to “time-out” in the same manner.
The indicator LED on the hand-held
remote will go off when the device times
out, indicating that it has finished transmit-
ting.
If you live in Canada or you are having
difficulties programming a gate operator or
garage door opener by using the program-
ming procedures, replace “Programming a
New HomeLink ® button” step 3 with the
following:
While the HomeLink ® indicator light is
flashing orange, press and release (“cy-
cle”) your device’s hand-held remote every
two seconds until the HomeLink ® indicator
light changes from orange to green. You
may now release the hand-held remote
button.
NOTE
If programming a garage door opener
or gate operator, it is advised to unplug
