Instruments and controls/Wiper and washer
& Windshield wiper and washer
switches
S03AM01
The wiper operates only when the ignition
switch is in the “ON” position.
For a single wipe of the wipers, push the
lever up. The wipers operate until you
release the lever.
! Wiper intermittent time control
3-63
! Windshield washer
S03AM0104
S03AM0103
! Windshield wipers
S03AM0101
: Mist (for a single wipe)
: Off
When the wiper switch is in the “ ”
position, turn the dial to adjust the operat-
ing interval of the wiper. The operating
interval can be adjusted in several steps
from the shortest interval to the longest.
To wash the windshield, pull the wiper
control lever toward you. The washer fluid
sprays until you release the lever. The
wipers operate while you pull the lever.
: Intermittent
: Low speed
: High speed
To turn the wipers on, push the wiper
control lever down.
To turn the wipers off, return the lever to
the “ ” position.
– CONTINUED –
