Instruments and controls/Light control switch
1)
Automatic dimming on/off button
2. Press and hold the automatic dimming
on/off button for 15 to 20 seconds.
When the sensitivity of the high beam
assist function is lowered, the LED indi-
cator on the automatic dimming on/off
button will flash.
NOTE
. The sensitivity of the high beam
assist function cannot be lowered while
driving.
. You can resume the sensitivity of the
high beam assist function by using
either of the following operations.
– Turn the ignition switch to the
“LOCK”/“OFF” position and then
start the engine.
– Press and hold the automatic
dimming on/off button for 15 to 20
seconds again.
Type B:
1. Before turning the ignition switch to the
“ON” position, set the light control switch to
the “AUTO” position and push the signal
lever forward (high beam position).
2. Turn the ignition switch to the “ON”
position and within approximately 15 sec-
onds, press the “ / ” (following distance
setting) switch more than 10 times con-
secutively.
When the sensitivity of the high beam
assist function is lowered, the high beam
assist indicator light “
” (yellow) on the
combination meter will flash.
NOTE
. The sensitivity of the high beam
assist function cannot be lowered in
the following conditions.
– Cruise control or Adaptive Cruise
Control is in operation
– The EyeSight warning indicator
(yellow) is illuminated
3-55
. The sensitivity of the high beam
assist function returns to normal level
the next time the ignition switch is
turned to the “LOCK”/“OFF” position
and the engine is restarted.
! How to change the headlight mode
manually
S03AH0702
Change to the low beam:
When you return the turn signal lever to the
center position, the high beam assist
function will turn off and the high beam
assist indicator will turn off.
Change to the high beam:
When you turn the light control switch to
the “ ” position, the headlight mode will
be changed to the high beam.
At this time, the high beam assist function
will turn off, the high beam assist indicator
will turn off and the high beam indicator
light will turn on.
NOTE
. After manually changing the head-
light mode to the high beam, if you turn
on the high beam assist function,
return the light control switch to the
“AUTO” position.
. When manually changing the head-
light mode to the high beam, if you turn
the light control switch to the “
”
position, the parking lights, front side
– CONTINUED –
