3-54
Instruments and controls/Light control switch
! How to use the high beam assist
function
S03AH0701
The high beam assist function will be
activated when all the following conditions
are met.
. The light control switch is in the “AUTO”
position and the low beam headlights are
on automatically.
. The turn signal lever is pushed forward.
! Malfunction of the high beam assist
function
S03AH0705
If the high beam assist function is mal-
functioning or is temporarily stopped, the
headlight will be fixed at low beam.
High beam assist warning indicator (yel-
low)
High beam assist indicator (green)
When the high beam assist function is
activated, the high beam assist indicator
on the combination meter will illuminate.
When the high beam assist function
malfunctions, the high beam assist warn-
ing indicator on the combination meter will
appear. In this case, have your vehicle
inspected by your SUBARU dealer.
! Temporary stop of high beam assist
function
S03AH0706
If the high beam assist function stops
temporarily due to poor visibility or abnor-
mal temperature, the message appears on
the combination meter. Once the condi-
tions have been remedied, drive the
vehicle for a while to restore the system.
NOTE
Even when the operation conditions of
the high beam assist function are met,
there may be a case in which the high
beam assist indicator does not illumi-
nate.
Type A:
In this case, turn the ignition switch to
the “LOCK”/“OFF” position and then to
the “ON” position again. Check if the
high beam assist indicator illuminates.
If the indicator does not illuminate,
have the vehicle inspected at a
SUBARU dealer.
Type B:
For details, refer to the Owner’s Manual
supplement for the EyeSight system.
! How to temporarily lower the sensi-
tivity of the high beam assist func-
tion
S03AH0704
The sensitivity of the high beam assist
function can be lowered by using the
following operations.
Type A:
1. Turn the ignition switch to the “ON”
position.
