B
Wiper and washer switch
1
1 Windshield wiper
To operate the wiper, rotate knob to;
: Mist (for a single wipe)
: Off
: Intermittent
: Low speed
: High speed
2
3
2 Wiper intermittent time control
3 Windshield washer
4
4 Rear window wiper and washer
To operate the wiper, rotate knob to;
: Continuous
: Intermittent
: Off
: Washer
Rotate knob to
wiper operates.
. The washer fluid sprays and the
C
Hazard warning flasher switch
To turn on the hazard warning flasher, press the button.
Use the hazard warning flasher when you have to park
in emergency conditions.
D
Illumination brightness control dial
Turn the dial to adjust the illumination brightness of the
instrument panel.
When the control dial is turned fully upward to
position, the illumination brightness becomes the
maximum and the automatic dimming function does not
work at all.
*The design may be slightly different from the
illustration depending on the models.
7
