7-70
Starting and operating/Reverse Automatic Braking System
When the OFF setting is shown, the
corresponding setting is OFF.
Touch and hold the OFF setting key to turn
the setting ON.
When the Reverse Automatic Braking
system and/or the object detection warning beeping sounds are turned OFF, the
following indicator(s) will illuminate.
1)
2)
RAB OFF indicator: illuminates when the
Reverse Automatic Braking system is
turned OFF.
Sonar audible alarm OFF indicator:
illuminates when the object detection
warning beeping sound is turned OFF.
Each indicator will turn off when the
corresponding function is turned ON.
NOTE
. When the settings cannot be changed, the ON/OFF setting key will be
grayed out.
. The settings cannot be changed for
approximately 14 seconds after turning
the ignition switch to the “ON” position.
. The ON/OFF setting key may be
greyed out if the Reverse Automatic
Braking system malfunctions, etc. In
this case, turn the ignition switch to the
“LOCK”/“OFF” position and then turn it
to the “ON” position again. If the
setting cannot be changed even after
turning the ignition switch to the “ON”
position again, consult your SUBARU
dealer.
. The settings will be restored as
follows when the select lever is shifted
to the “R” position next time.
– Reverse Automatic Braking system settings: default (ON setting)
– Object detection warning beeping sound: the setting selected by
operating the multi function display
Also, the following settings can be changed by operating the multi information
display.
. Warning volume
. Sonar audible alarm
For details, refer to “RAB” F3-45.
& Handling of the sonar sensors
The 4 sonar sensors are located in the
rear bumper. To ensure the proper operation of the Reverse Automatic Braking
system, observe the following precautions.
. Do not affix any stickers or other items
on the bumper surface near the sonar
sensors.
. Always keep the rear bumper surface
near the sonar sensors clean.
. Do not modify the rear bumper.
. Do not paint the bumper near the sonar
sensors.
. Do not apply strong impacts to the rear
