7-66
Starting and operating/Reverse Automatic Braking System
near the sonar sensor
– Commercial electronic parts
(fog light, fender pole, radio
antenna) or commercial attachment parts (trailer hitch,
bicycle carrier, bumper guard)
are attached
– Parts that emit high frequency
sound, such as a horn or
speaker, are attached
Vehicle conditions
– The vehicle is significantly
inclined
– The ground clearance is significantly reduced due to the
vehicle’s loading condition,
etc.
– When the sonar sensor is
misaligned due to a collision
or an accident
Surrounding environment
– A cloth banner, flag, hanging
branch or railroad crossing
bars are present in the reversing direction
– When reversing on a gravel or
grassy area
– When reversing in an area
where objects or walls are
adjacent to the vehicle such
–
–
–
–
–
as narrow tunnels, narrow
bridges, narrow roads or narrow garages
Wheel track or hole is present
in the ground of the reversing
direction
When reversing over a drainage cover (grating cover)
The path of the reversing
direction is inclined such as
on a steep uphill
A curb is present in the reversing direction
When reversing downhill
NOTE
The Reverse Automatic Braking system will operate at vehicle speed
between 1 to 9 mph (1.5 to 15 km/h).
However, stopping the vehicle by automatic hard braking is designed to
operate when the vehicle speed is less
than 3 mph (5 km/h).
& Reverse Automatic Braking
System operation
When Reverse Automatic Braking System
is in operation, an audible warning beeps
will sound in 3 levels to warn the driver of
a potential collision.
1) First braking and warning:
When the system detects an object, if the
vehicle is kept reversing, the system
determines a collision with an object may
occur. In this case, short warning beeps
will sound and automatic deceleration will
be activated. Also, a warning message will
be indicated on the audio/navigation
monitor.
Example: The path of the reversing direction is inclined such as on a steep uphill.
