About EyeSight
■ EyeSight temporary stop indicator (white)
x This indicator illuminates when the EyeSight system is temporarily stopped.
x When the ignition switch is placed in the ON position, it will illuminate if the
(CRUISE) switch or
(Lane Keep Assist) switch are set to ON within approximately 7
seconds of the engine starting. It turns off when approximately 7 seconds have elapsed
since the engine started.
x When it is illuminated, none of the EyeSight functions can be used except for Conventional Cruise Control.
Refer to page 87.
■ Lane Departure Warning OFF indicator light
x This indicator illuminates when the Lane Departure Warning and Lane Sway Warning are
off.
x It also illuminates when the ignition switch is turned to the ON position, and then approximately 7 seconds after the engine starts, the Lane Departure Warning will be turned off or
remain illuminated depending on the current status (ON or OFF).
Refer to page 70.
■ Pre-Collision Braking System OFF indicator light
x Illuminates when the Pre-Collision Braking System and Pre-Collision Throttle
Management are off.
x It also illuminates when the ignition switch is turned to the ON position, and then turns off
approximately 7 seconds after the engine starts.
Refer to page 31.
■ Vehicle Dynamics Control OFF indicator light
x It illuminates when the engine starts and turns off within approximately 2 seconds.
x It illuminates when the Vehicle Dynamics Control OFF switch is pressed and Vehicle
Dynamics Control is off. Refer to the Owner’s Manual for your vehicle.
■ Brake system warning light (red)
If the brake system warning light should illuminate while driving with the parking brake fully
released, turn off the Pre-Collision Braking System. Also, do not use Adaptive Cruise Control or Conventional Cruise Control.
■ Electronic parking brake indicator light
This indicator light illuminates when the electronic parking brake is applied.
Refer to the Owner’s Manual for details.
■ Vehicle Dynamics Control warning light
This indicator illuminates when the engine switch is turned to the “ON” position, and turns
off approximately 2 seconds after the engine is started. It will illuminate if there is a malfunction in the VDC electrical control system.
* Refer to the Owner’s Manual for details.
