About EyeSight
■ Following distance setting indicator
Indicates the following distance setting that was set with the
setting) switch.
Refer to page 45.
/
(Following distance
■ Set vehicle speed display
Displays the set vehicle speed.
Refer to pages 38 and 76.
■ Your vehicle indicator
When the brake pedal is depressed or the brake control function is active, the brake light on
the indicator illuminates in red.
■ Lane Keep Assist indicator
x This indicator illuminates when Lane Keep Assist is turned on by pressing the
(Lane
Keep Assist) switch.
x While the Lane Keep Assist system is activated, if the vehicle travels across a lane
marker, the indicator turns from white to green.
Refer to pages 54 and 58.
■ Select lever/gear position indicator
This indicator illuminates and shows which position the select lever or the gear is in.
■ Lane indicator
x When Lane Keep Assist is in the standby status or is operating, the lane indicator of the
detected lane will illuminate (left, right or both left and right).
x Either the left or right indicator blinks depending on which side your vehicle is drifting
towards when Lane Departure Warning operates.
x The left and right indicators alternately blink when Lane Sway Warning operates.
Refer to pages 68 and 71.
■ EyeSight warning indicator (yellow)
x This indicator illuminates or flashes when a malfunction occurs in the EyeSight system.
x When it is illuminated or flashing, none of the EyeSight functions can be used (including
Adaptive Cruise Control and the Pre-Collision Braking System, etc.).
Refer to page 86.
15
