2-34
Keys and doors/Windows
& Power window operation by
driver
! Operating the driver’s/front pas-
senger’s window
! Driver’s side power window
switches
1)
2)
1)
2)
3)
4)
5)
Lock switch
For driver’s window
For front passenger’s window
For rear left passenger’s window
For rear right passenger’s window
All door windows can be controlled by the
power window switch cluster at the driver
side door.
Automatically open/close*
Open/close
*: For some models, the automatic open/close
function (one touch auto up/down function) is
not available for the front passenger’s window.
To open:
Press the switch down lightly and hold it.
The window will open as long as the
switch is held.
NOTE
If you continue to hold the AUTO
switch in the down position after the
window has been fully opened, the
circuit breaker may activate for a short
time and the window may not operate.
Allow several seconds for the system
to reset without touching the switch,
and the window will begin to operate
normally on its own.
This switch also has a one-touch auto
down function that allows the window to
be opened fully without holding the switch.
Press the switch down until it clicks and
release it, and the window will fully open.
To stop the window halfway, pull the
switch up lightly.
To close:
Pull the switch up lightly and hold it. The
window will close as long as the switch is
held.
NOTE
If you continue to hold the AUTO
switch in the up position after the
window has fully closed, the circuit
breaker may open and the system may
not operate. After several seconds, the
window will be able to be opened by
holding the switch down until it is fully
opened. The AUTO function will not
