3-58
Instruments and controls
applicator.
& Auto-dimming mirror with
HomeLink® (if equipped)
turned on or off. When the automatic
dimming function is on, the LED indicator
will illuminate.
Even with the mirror in the automatic
dimming mode, the mirror surface turns
bright if the shift lever/select lever is
shifted into the “R” (reverse) position. This
is to ensure good rearward visibility during
reversing.
When cleaning the mirror, use a paper
towel or similar material dampened with
glass cleaner. Do not spray glass cleaner
directly on the mirror as that may cause
the liquid cleaner to enter the mirror
housing and damage the mirror.
! Photosensors
1)
2)
3)
4)
5)
6)
7)
There are three HomeLink® buttons on the
mirror, each of which can be programmed
for operation of one desired device. For
details on the device types which can be
operated by this system, consult the
HomeLink® website at:
www.homelink.com or call 1-800-3553515.
HomeLink® button 1
HomeLink® button 2
LED
HomeLink® button 3
Sensor
Automatic dimming on button
Automatic dimming off button
The auto-dimming mirror has an anti-glare
feature which automatically reduces glare
coming from headlights of vehicles behind
you. It also contains a HomeLink® wireless
control system.
By pressing the automatic
