Instruments and controls
& Auto-dimming mirror (if
equipped)
3-57
reward visibility during reversing.
When cleaning the mirror, use a paper
towel or similar material dampened with
glass cleaner. Do not spray glass cleaner
directly on the mirror as that may cause
the liquid cleaner to enter the mirror
housing and damage the mirror.
! Photosensors
1)
2)
3)
HomeLink® button 1
HomeLink® button 2
HomeLink® button 3
1. Press and hold the two outer buttons
(button 1 and button 3) until the indicator
light begins to flash (after approximately
20 seconds).
2. Release both buttons.
! In case a problem occurs
If you cannot activate a device using the
corresponding HomeLink® button after
programming, contact HomeLink® at
www.homelink.com or call 1-800-3553515 for assistance.
1)
2)
3)
LED
Switch
Sensor
The auto-dimming mirror has an anti-glare
feature which automatically reduces glare
coming from headlights of vehicles behind
you.
By pressing and holding the switch for
less than 3 seconds, the automatic dimming function is toggled on or off. When
the automatic dimming function is on, the
LED indicator will illuminate.
Even with the mirror in anti-glare mode,
the mirror surface turns bright if the shift
lever/select lever is shifted into the “R”
(reverse) position. This is to ensure good
The mirror has a photosensor attached on
the front and back sides. During nighttime
driving, these sensors detect distracting
glare from vehicle headlights behind you
and automatically dim the mirror to eliminate glare and preserve your vision. For
this reason, use care not to cover the
sensors with stickers, or other similar
items. Periodically wipe the sensors clean
using a piece of dry soft cotton cloth or an
– CONTINUED –
