Pre-Collision Braking System
Pre-Collision Braking System operation
When there is an obstacle in the forward direction during driving, the system activates in the
following sequence in order to warn the driver, activate braking control, and active the brake
lights.
Following Distance Warning:
When the system determines that there is a risk of collision, a buzzer sounds repeated short
beeps and the indicators on the multi information display illuminate to warn the driver.
The Following Distance Warning operates when Adaptive Cruise Control is not set.
When the driver depresses the brake pedal to decelerate and achieves a suitable following
distance, the warning is canceled.
First Braking and Warning:
When the system determines that there is a high risk of collision with an obstacle in front, a
buzzer sounds repeated short beeps and the indicators on the multi information display illuminate to warn the driver, and braking control is activated. If the system determines that the
amount of evasive action (braking, steering, etc.) taken by the driver has reduced the risk of
collision, braking activation is canceled.
Second Braking and Warning:
If the system then determines that the risk of collision is extremely high, the buzzer changes
to a continuous beeping sound and stronger braking control is activated. If, despite any evasive action taken by the driver, the system subsequently determines that a collision is
unavoidable, braking control is continued.
Even after the vehicle has stopped, braking control will continue. (Stop is maintained)
Obstacle
First braking
& warning
Following distance
warning
Second braking
& warning
Possible collision area
Highly possible
Extremely highly possible
collision area
collision area
Illumination of tracking
Warning
Operating Strength of
cruise control indicator and
Automatic Braking
system
following distance warning light buzzer type
Following
Repeated
No brake control
distance
short beeps
warning
First
braking
Moderate
Repeated
short beeps
Second
braking
Strong
Continuous
beep
* Models for Canada: Metric units are used.
S00579
46
