About EyeSight
GLane Departure Warning OFF indicator light
This indicator illuminates when the Lane Departure Warning and Lane Sway Warning are
off.
It also illuminates when the ignition switch is turned to the ON position, and then approximately 7 seconds after the engine starts, it turns on or off depending on the current status
(ON or OFF).
* Refer to page 56.
GPre-Collision Braking System OFF indicator light
Illuminates when the Pre-Collision Braking System and Pre-Collision Throttle
Management are off.
It also illuminates when the ignition switch is turned to the ON position, and then turns off
approximately 7 seconds after the engine starts.
* Refer to pages 48 and 53.
GEyeSight warning indicator (yellow)
This indicator illuminates or flashes when a malfunction occurs in the EyeSight system.
When it is illuminated or flashing, none of the EyeSight functions can be used (including
Adaptive Cruise Control and the Pre-Collision Braking System, etc.).
* Refer to page 71.
GEyeSight temporary stop indicator (white)
This indicator illuminates when the EyeSight system is temporarily stopped.
When the ignition switch is placed in the ON position, it will illuminate if the CRUISE
switch is set to ON within approximately 7 seconds of the engine starting. It turns off when
approximately 7 seconds have elapsed since the engine started.
When it is illuminated, none of the EyeSight functions can be used except for Conventional Cruise Control.
* Refer to page 72.
GLane indicator
When the Lane Departure Warning is activated, both the left and right indicators flash
simultaneously.
When the Lane Sway Warning is activated, the left and right [
