5-24
Audio
MP3:
. Based on MPEG 1, 2 and 2.5 Layer 3
(type A and B audio)
. Based on MPEG 1, 2 and 2.5 Layer 2
and 3 (type C audio)
. Sampling rate (kHz): 48, 44.1, 32, 24,
22.05, 16, 12, 11.025, 8
. Bit rate (kbps): 8 to 320 (type A and B
audio)
. Bit rate (kbps): 32 to 320 (type C audio)
. Supports variable bit rates
WMA (type B audio):
. Based on Windows Media Audio 9
. Sampling rate (kHz): 48, 44.1, 32
. Bit rate (kbps): 32 to 192
WMA (type C audio):
. Based on Windows Media Audio 7, 8
and 9
. Sampling rate (kHz): 48, 44.1, 32
. Bit rate (kbps): 32 to 192
AAC (type B audio):
. Based on MPEG4 AAC
. Sampling rate (kHz): 48, 44.1, 32, 24,
22.05, 16, 12, 11.025, 8
. Bit rate (kbps): 24 to 320
. Number of channels: 1 to 2ch
AAC (type C audio):
. Based on MPEG2 AAC and MPEG4
AAC
. Sampling rate (kHz): 48, 44.1, 32, 24,
22.05, 16, 12, 11.025, 8
. Bit rate (kbps): 24 to 320
. Number of channels: 1 to 2ch
& How to insert a CD
While the ignition switch is in the “Acc” or
“ON” position, hold a disc with a finger in
the center hole while gripping the edge of
the disc, then insert it in to the slot (with
the label side up) and the player will
automatically pull the disc into position.
! When CD is in the player (type A)
When the
button is pressed, the
player will start playback.
! When CD is in the player (type B
and C)
Type B audio
Type C audio
Each brief press of the “CD/AUX” button
changes the modes in the following
sequence.
NOTE
DO NOT INSERT TWO DISCS INTO THE
DISC INSERTION SLOT AT A TIME.
& How to play back a CD
! When there is no CD inserted
Insert a CD by referring to “How to insert a
CD” F5-24.
When a CD is loaded, the player will start
playback of the CD, beginning with the
first track.
*: For type B audio, “BT-A” is displayed.
When the CD mode is selected, the player
will start playback.
& To select a track from the
beginning
NOTE
With an MP3, WMA or AAC:
. Skipping past the last track/file will
take you back to the first track/file in
the folder.
