4-10
Climate control
! AUTO button
FULL AUTO mode operation:
you operated. To change the system back
to the FULL AUTO mode, press the
“AUTO” button.
! OFF button
! Temperature control button
Driver’s side
When the “AUTO” button is pressed, the
indicator light “FULL AUTO” on the display
illuminates. In this state, fan speed, air
flow distribution, air-inlet control, and air
conditioner compressor operation are
automatically controlled.
AUTO mode operation:
If you operate any of the buttons on the
control panel other than the “OFF” button,
rear window defogger button and temperature control buttons during FULL
AUTO mode operation, the indicator light
“FULL” on the control panel will turn off
and the indicator light “AUTO” will remain
illuminated. You can then manually control
the system as desired using the button
The automatic climate control system
turns off (the air conditioner compressor
and fan turn off) when the “OFF” button is
pressed.
When the “OFF” button is pressed, the
outside air circulation mode (air inlet
selection OFF) is automatically selected.
Passenger’s side
To increase the temperature setting, press
the “ ” side of the temperature control
