brake , refer to “ Electronic Parking
Brake ” FP388 . – When 2 minutes pass after the vehicle is stopped – When any door is opened . The Reverse Automatic Braking ( RAB ) system may stop operating temporarily in the following cases and the RAB OFF indicator will illuminate . – Ice , snow or mud is adhered to the sonar sensors or the rear bumper near the sonar sensor – Objects are too close to the rear bumper when the select lever is set to the “ R ” position – The system detects sounds of a similar frequency to the RAB sonar
& Canceling the Reverse Automatic Braking ( RAB ) System Operation s07bn04
The Reverse Automatic Braking ( RAB ) system can be temporarily canceled by any of the following operation .
. While the vehicle is stopped by the operation of automatic braking , the brake pedal is depressed .
. While the vehicle is stopped by the operation of automatic braking , the accelerator pedal is depressed .
|
. The accelerator pedal is depressed continuously ( In this case , limited acceleration will be canceled and the vehicle will continue reversing .)
. The select lever is shifted to a position other than the “ R ” position .
NOTE
The system will be canceled if the object is no longer detected .
& Reverse Automatic Braking ( RAB ) System ON / OFF Setting s07bn05
While the select lever is shifted to the “ R ” position , the below functions of the Reverse Automatic Braking ( RAB ) system can be set by operating the center information display .
|
1 ) ON setting key of Automatic Braking function
2 ) OFF setting key of Automatic Braking function
3 ) ON setting key of the Sonar Audible Alarm function
4 ) OFF setting key of the Sonar Audible Alarm function
When the ON setting key is shown , the corresponding setting is ON .
Touch and hold the ON setting key to turn the setting OFF .
When the OFF setting is shown , the corresponding setting is OFF .
Touch and hold the OFF setting key to turn the setting ON .
When the Automatic Braking function is turned OFF , the following indicator ( s ) will illuminate .
|
7
Starting and Operating
|
||
– CONTINUED – |
