308
Automatic Climate Control Operation
4-3 . Automatic Climate Control Operation
s04ai
Climate control screen ( dual 7.0-inch display models )
Climate control screen ( 11.6-inch display |
models ) |
1 ) |
Air inlet selection |
2 ) |
Air conditioner |
3 ) |
Airflow mode |
4 ) |
Fan speed |
When the auto mode is selected , the following functions are automatically controlled .
. Fan speed . Airflow mode . Air inlet selection . Air conditioner operation
To activate this mode , perform the following .
1 . Touch the climate control mode indicator .
2 . Touch “ AUTO ”.
3 . Set the preferred temperature . Refer to “ Temperature Control ” FP311 .
NOTE
. Operate the automatic climate control system when the engine is running . . Even when cooling is not necessary , the air conditioner will automatically turn on if the temperature is set much lower than the current outlet air temperature . Even in this case , the “ A / C ” indicator light on the climate control screen illuminates . . The air conditioner may not operate in the following cases : – When the cabin temperature is low – When the ambient temperature decreases close to 328F ( 08C ) . The controllable temperature range may vary depending on the regional specifications of the vehicle . . When “ AUTO ” is displayed , if you operate the fan speed control or the airflow mode , press the defroster button , or turn on MAX A / C mode , the “ AUTO ” display will turn off . You can then manually control the system as desired using the climate control screen . To change the system back to auto mode , touch “ AUTO ”.
