Mirrors 283
Left / right adjustment
Rotation adjustment
! Dimming setting s03ap110306
The Smart Rearview Mirror has a dimming mirror mode . When the mirror mode is selected with the ignition switch in the “ ON ” position , auto dimming will activate . This mode decreases glare automatically depending on the brightness level from behind .
3
1 )
Setting button : Press the setting button to
set the angle .
2 )
Press this button to turn the angle left .
3 )
Press this button to turn the angle right .
After pressing the setting button , the mode will change to the rotation adjustment mode .
NOTE
If the button is not touched for 5 seconds , the left / right adjustment menu will exit .
1 ) Setting button : Press the setting button to set the angle .
2 ) Press this button to turn the angle counterclockwise .
3 ) Press this button to turn the angle clockwise .
After pressing the setting button , the mode will change to the HomeLink menu .
NOTE
If the button is not touched for 5 seconds , the rotation adjustment menu will finish .
1 )
Left button
2 )
Center button
3 )
Right button
When selecting the mirror mode , press any of the buttons to display the auto dimming menu . Press the center or right buttons to turn the dimming mirror mode ON / OFF .
Instruments and Controls
– CONTINUED –
