282
Mirrors
. When using the display mode , parts of the vehicle interior may reflect light on the display . Adjust the angle of the Smart Rearview Mirror to avoid unwanted reflection .
Brightness adjustment Up / down adjustment
! Display adjustment s03ap110307
1 ) |
Left button |
2 ) |
Center button |
3 ) |
Right button |
Press any of the left , center or right buttons to display the main menu .
NOTE
The main menu cannot be displayed on the display while the select lever is in a position other than the “ P ” position .
1 ) Setting button : Press the setting button to set the brightness .
2 ) Press this button to decrease the brightness .
3 ) Press this button to increase the brightness .
After pressing the setting button , the mode will change to the up / down adjustment mode .
NOTE
If the button is not touched for 5 seconds , the brightness adjustment menu will exit .
1 ) |
Setting button : Press the setting button to |
set the angle . |
2 ) |
Press this button to lower the angle . |
3 ) |
Press this button to raise the angle . |
After pressing the setting button , the mode will change to the left / right adjustment mode .
NOTE
If the button is not touched for 5 seconds , the up / down adjustment menu will exit .
