Mirrors 277 |
|||||
|
the device during the “ cycling ” process to prevent possible overheating .
Proceed with “ Programming a New HomeLink ® button ” step 4 to complete .
! Using HomeLink ® s03ap100303
To operate , simply press and release the programmed HomeLink ® button . Activation will now occur for the trained device ( i . e . garage door opener , gate operator , security system , entry door lock , home / office lighting , etc .). For convenience , the hand-held remote of the device may also be used at any time .
! Erasing HomeLink ® buttons s03ap100304
To erase programming from the three buttons ( individual buttons cannot be erased but can be “ reprogrammed ” as outlined below ), follow the step noted :
Press and hold the two outer HomeLink ® buttons for at least 10 seconds . The LED indicator will change from continuously lit to rapidly flashing . Release both buttons . Do not hold for longer than 20 seconds . HomeLink ® is now ready to be programmed at any time beginning with “ Programming a New HomeLink ® button ” - step 1 .
|
! Reprogramming a Single HomeLink ® button s03ap100305
To program a previously trained button , follow these steps :
1 . Press and hold the desired HomeLink ® button . DO NOT release the button .
2 . The indicator light will begin to slowly flash orange after 20 seconds . The HomeLink ® button can be released at this point . Proceed with “ Programming a New HomeLink ® button ” - step 3 .
3 . If you do not complete the programming of a new device to the button , it will revert to the previously stored programming .
! Garage Door Two-Way Communication s03ap100306
HomeLink ® has the capability of communicating with your garage door opener . HomeLink ® can receive and display “ closing ” or “ opening ” status messages from compatible garage door opener systems . At any time , HomeLink ® can also recall and display the last recorded status communicated by the garage door opener to indicate your garage door being “ closed ” or “ opened ”.
HomeLink ® has the capability of receiving this communication from the garage door opener at a range up to 820 feet ( 250 m ).
|
Range may be reduced by obstacles such as houses or trees . You may have to slow your vehicle speed to successfully receive the garage door opener communication .
! Programming Two-Way Communication s03ap100307
1 ) Status Indicators
Within 5 seconds after programming a new HomeLink ® button , both of HomeLink ’ s garage door status indicators will flash rapidly green indicating that the garage door two-way communication has been enabled . If your garage door status indicators flashed , two-way communication programming is complete .
If the garage door status indicators do not flash , additional HomeLink ® information and programming videos can be found
– CONTINUED –
|
