1-40
Seat, seatbelt and SRS airbags/Child restraint systems
! Tether anchorage location
! Outback
S01AG0901
S01AG090102
! Legacy
S01AG090101
installed on the back side of the rear
seatback.
! To hook the top tether
S01AG0902
CAUTION
Always raise the head restraint
when mounting a child restraint
system with a top tether. Failure to
do so may prevent the top tether
from being fastened tightly.
! Legacy
S01AG090201
Three tether anchorages are installed on
the rear shelf behind the rear seat head
restraint. Open the cover flap to use each
anchorage.
1)
2)
3)
For left seat
For center seat
For right seat
Three tether anchorages, i.e., ones for the
right, center and left positions, are already
1)
2)
When installing on the window-side
seating position
When installing on the rear center seating
position
1. Raise the head restraint at the seating
