Starting and operating/Reverse Automatic Braking System
& RAB warning indicator
S07BN07
& Reverse Automatic Braking
system ON/OFF setting
S07BN05
While the select lever is shifted to the “R”
position, the below functions of the Re-
verse Automatic Braking system can be
set by operating the audio/navigation
monitor.
7-67
When the OFF setting is shown, the
corresponding setting is OFF.
Touch and hold the OFF setting key to turn
the setting ON.
When the Reverse Automatic Braking
system and/or the object detection warn-
ing beeping sounds are turned OFF, the
following indicator(s) will illuminate.
If the Reverse Automatic Braking System
malfunctions, the above indicator illumi-
nates on the combination meter. Contact
the nearest SUBARU dealer for details.
1)
2)
3)
4)
ON setting key of Reverse Automatic
Braking
OFF setting key of Reverse Automatic
Braking
ON setting key of the object detection
warning beeping sound
OFF setting key of the object detection
warning beeping sound
When the ON setting key is shown, the
corresponding setting is ON.
Touch and hold the ON setting key to turn
the setting OFF.
1)
2)
RAB OFF indicator: illuminates when the
Reverse Automatic Braking system is
turned OFF.
Sonar audible alarm OFF indicator: illu-
minates when the object detection warn-
ing beeping sound is turned OFF.
Each indicator will turn off when the
corresponding function is turned ON.
– CONTINUED –
