7-66
Starting and operating/Reverse Automatic Braking System
! After the vehicle is stopped by the
system
S07BN0304
1)
Reverse Automatic Braking system OFF
indicator
After the brake pedal is depressed, the
Reverse Automatic Braking system OFF
indicator will illuminate and the system will
temporarily stop operating. The Reverse
Automatic Braking system OFF indicator
will turn off when the select lever is shifted
to a position other than the “R” position.
The system will operate again the next
time the select lever is shifted to “R”
position.
NOTE
. In the following cases, after the
vehicle has been stopped by the Re-
verse Automatic Braking system, brake
control is released and the electronic
parking brake operates. For details
about releasing the parking brake, refer
to “Electronic parking brake” F7-40.
– When 2 minutes pass after the
vehicle is stopped
– When any door is opened
. The Reverse Automatic Braking sys-
tem may stop operating temporarily in
the following cases and the Reverse
Automatic Braking system OFF indica-
tor will illuminate.
– Ice, snow or mud is adhered to
the sonar sensors or the rear bum-
per near the sonar sensor
– Objects are too close to the rear
bumper when the select lever is set
to the “R” position
– The system detects sounds of a
similar frequency to the RAB sonar
& Canceling the Reverse Auto-
matic Braking system opera-
tion
S07BN04
The Reverse Automatic Braking system
can be temporarily canceled by any of the
following operation.
. While the vehicle is stopped by the
operation of automatic braking, the brake
pedal is depressed.
. While the vehicle is stopped by the
operation of automatic braking, the accel-
erator pedal is depressed.
. The accelerator pedal is depressed
continuously (In this case, limited accel-
eration will be canceled and the vehicle will
continue reversing.)
. The select lever is shifted to a position
other than the “R” position.
NOTE
The system will be canceled if the
object is no longer detected.
