Subaru Legacy Manuals 2019 Legacy Owner's Manual | Seite 242

3-86
Instruments and controls/Horn
Horn
S03AR
Heated Steering Wheel sys-
tem (if equipped)
S03BM
The Heated Steering Wheel system
warms the steering wheel at a constant
temperature.
1)
2)
Tilt adjustment
Telescopic adjustment
1. Adjust the seat position. Refer to “Front
seats” F1-2.
2. Pull the tilt/telescopic lock lever down.
3. Move the steering wheel to the desired
level.
4. Pull the lever up to lock the steering
wheel in place.
5. Make sure that the steering wheel is
securely locked by moving it up and down,
and forward and backward.
To sound the horn, push the horn pad.
1)
2)
3)
Heated Steering Wheel switch
Indicator light
Heated area
To turn on the Heated Steering Wheel
system, pull the Heated Steering Wheel
switch when the ignition switch is in the
“ON” position. Then the steering wheel will
be warmed and the indicator light on the
switch will illuminate. To turn off the Heated
Steering Wheel system, pull the switch
again. Then the indicator light will turn off.
