Instruments and controls/Mirrors
1)
Status Indicators
8. If status indicator arrows appear next
to the indicator light, please refer to
“Garage Door Two-Way Communication”
F3-82.
In the event that there are still program-
ming difficulties or questions, additional
HomeLink ® information and programming
videos can be found at
www.HomeLink.com and
www.youtube.com/HomeLinkGentex. For
Genie and Sommer garage door openers
please go directly to the HomeLink ®
website.
3-81
! Gate Operator / Canadian Pro-
gramming
S03AP100302
Canadian radio-frequency laws require
transmitter remote signals to “time-out”
(or quit) after several seconds of transmis-
sion, which may not be long enough for
HomeLink ® to pick up the signal during
programming. Similar to this Canadian
law, some U.S. gate operators are de-
signed to “time-out” in the same manner.
The indicator LED on the hand-held
remote will go off when the device times
out, indicating that it has finished transmit-
ting. the device during the “cycling” process
to prevent possible overheating.
Proceed with “Programming a New
HomeLink ® button” step 4 to complete.
If you live in Canada or you are having
difficulties programming a gate operator or
garage door opener by using the program-
ming procedures, replace “Programming a
New HomeLink ® button” step 3 with the
following: ! Erasing HomeLink ® buttons
S03AP100304
To erase programming from the three
buttons (individual buttons cannot be
erased but can be “reprogrammed” as
outlined below), follow the step noted:
While the HomeLink ® indicator light is
flashing orange, press and release (“cy-
cle”) your device’s hand-held remote every
two seconds until the HomeLink ® indicator
light changes from orange to green. You
may now release the hand-held remote
button.
NOTE
! Using HomeLink ®
S03AP100303
To operate, simply press and release the
programmed HomeLink ® button. Activa-
tion will now occur for the trained device
(i.e. garage door opener, gate operator,
security system, entry door lock, home/
office lighting, etc.). For convenience, the
hand-held remote of the device may also
be used at any time.
Press and hold the two outer HomeLink ®
buttons for at least 10 seconds. The LED
indicator will change from continuously lit
to rapidly flashing. Release both buttons.
Do not hold for longer than 20 seconds.
HomeLink ® is now ready to be pro-
grammed at any time beginning with
“Programming a New HomeLink ® button”
- step 1.
If programming a garage door opener
or gate operator, it is advised to unplug
– CONTINUED –
