Instruments and controls/Steering Responsive Headlight (SRH)
then start the engine again, SRH will
automatically turn on.
. When you turn the ignition switch to
the “ON” position, the SRH OFF indi-
cator will illuminate and turn off after
several seconds.
. SRH only activates when the vehicle
is traveling forward at the speed of
approximately 5 mph (8 km/h) or more.
Steering Responsive Head-
light (SRH) (if equipped)
S03BL
1)
2)
1)
2)
The target area of illumination when SRH
is activated
The target area of illumination when SRH
is not activated
SRH is a function that automatically moves
the headlight beam to the left or right in
accordance with the steering angle. This
function helps to improve the visibility at
night by illuminating the road ahead at
corners and intersections.
You can turn the SRH function on or off.
The settings can be changed by using the
combination meter display. For details,
refer to “SRH” F3-46.
3-57
Warning screen
SRH OFF indicator
The SRH OFF indicator on the combina-
tion meter turns off when SRH is turned on.
The SRH OFF indicator on the combina-
tion meter illuminates when SRH is turned
off.
If SRH is malfunctioning, the SRH OFF
indicator on the combination meter blinks
and a message appears on the warning
screen when the ignition switch is in the
“ON” position. It indicates that SRH has
been deactivated. Contact a SUBARU
dealer for an inspection.
NOTE
. If you turn the ignition switch to the
“OFF” position with SRH turned off and
