1-8
Seat , seatbelt and SRS airbags / Seats
of sudden braking , or objects may move out from the cargo area or trunk . Both could cause serious injury or death .
& Head restraint WARNING
S01AQ04
The front seat head restraints are designed to be installed into the front seats only . The rear seat head restraints are designed to be installed into the rear seats only . Do not attempt to install the front seat head restraints into the rear seats , or the rear seat head restraints into the front seats .
NOTE
It is possible to adjust the angle of the front seat head restraints only . When installing the front seat head restraints , make sure that the angle of the head restraints can be adjusted .
! Front seats
S01AQ0401
Both the driver ’ s seat and the front passenger ’ s seat are equipped with head restraints . Both head restraints are adjustable in the following ways .
! Height adjustment
1 ) |
Head restraint |
2 ) |
Release button |
S01AQ040101
To raise : Pull the head restraint up . To lower :
Push the head restraint down while pressing the release button on the top of the seatback .
To remove :
While pressing the release button , pull out the head restraint .
To install :
Install the head restraint into the holes that are located on the top of the seatback until the head restraint locks . Press and hold the release button to lower the head restraint .
Each head restraint should be adjusted so that the center of the head restraint is closest to the top of the occupant ’ s ears .
NOTE
When the head restraint cannot be pulled out or installed due to insufficient clearance between the head restraint and the roof , tilt the seat and then perform the installation and removal tasks .
