Instruments and controls / Multi-function display ( color LCD ) 3-49
! Climate control screen ( if equipped )
S03BP1017
The climate control status is displayed on the multi-function display ( color LCD ).
When operating the climate control system , the basic screen switches to the climate control screen . For details about climate control operation , refer to “ Climate control panel ” F4-2 .
! Clock
S03BP1018
The clock can be displayed in either 12- hour display or 24-hour display . For details about the setting , refer to “ Clock ” F3-62 .
Climate control screen |
1 ) |
Set temperature indicator ( driver ’ s side ) |
2 ) |
FULL AUTO indicator |
3 ) |
AUTO indicator |
4 ) |
Airflow mode indicator |
5 ) |
Set temperature indicator ( passenger ’ s |
side )* 1
|
6 ) |
Air inlet selection indicator |
7 ) |
SYNC indicator * 1
|
8 ) |
Fan speed indicator |
9 ) |
Air conditioner ON indicator |
* 1 : Models with the SYNC function only |
– CONTINUED –
