412 STARTING AND OPERATING
Delete All Users
1. Touch( HOME). 2.?( Settings) 3.?“ Car” 4.?“ Driver Monitoring System” 5.?“ Delete All Users” 6.?“ Yes” s07bp0502
DRIVER MONITORING SYSTEM ON / OFF SETTINGS s07bp07
NOTE
. When the Driver Monitoring System is turned OFF after user recognition was completed, the user recognition function stores the Driver Monitoring System ON / OFF state.
. Even when the Driver Monitoring System is set to OFF, the Driver Monitoring System automatically turns ON once the driver’ s door is opened and closed while the vehicle is stopped. This only occurs when the user recognition setting is ON. The system then reverts automatically to the OFF state.
. After the Driver Monitoring System was turned OFF, if the Driver Monitoring System is turned ON while the driver’ s door is open, user recognition may not occur correctly.
To turn on / off the Driver Monitoring System s07bp0701
To turn the Driver Monitoring System on and off, operate the center information display. Refer to“ Settings icon( Car settings)” FP230. When the Driver Monitoring System is turned OFF, the Driver Monitoring System OFF indicator on the combination meter display will illuminate.
NOTE
Even when the Driver Monitoring System is turned off, the user recognition does not switch on or off automatically.
User recognition settings s07bp0702
The Driver Monitoring System User recognition function can be turned ON / OFF. For the setting procedure, refer to“ Settings icon( Car settings)” FP230.
NOTE
. The user recognition function setting cannot be changed for each individual user.
. The default setting for the user recognition function is ON.
. When the user recognition function is turned OFF, the following items cannot be selected.
– Repeat Facial Scan – Register User – Update Seat and Mirror Position – Delete Driver Position – Request Setting Update
Automatically retract seat on entry s07bp0704
The automatically retract seat on entry which automatically slides back the driver’ s seat when the driver’ s door is unlocked and opened.
This function can be turned ON / OFF. For the setting procedure, refer to“ Settings icon( Car settings)” FP230.
CAUTION
Sit in the seat after the power seat movement backward has been completed. Not doing so could result in injury.
NOTE
. If the seat position is not registered in the access key fob memory, the automatically retract seat on entry function can be used.
. Even when the automatically retract seat on entry setting is ON, the automatically retract seat on entry function automatically turns OFF when the user recognition function is
